Industrial Mobile Computer


● 5.2 inch High-Resolution Display
● Android 11, Cortex-A5 Octa-core 2.0
● Honeywell/Newland/Zebra 1D/ 2D Barcode Reader for data collection
● IP65 Standard
● Fingerprint /Facial Recognition as optional
● Potable, Fit in your hand design
● UHF RFID(Impinj E310 Chip)

  • Cortex-A53 Octa-core 23GHz Cortex-A53 Octa-core 23GHz
  • RAM+ROM: 3+32GB/4+64GB RAM+ROM: 3+32GB/4+64GB
  • 5.2 5.2" IPS 1080P creen
  • 5000mAh Powerful Battery 5000mAh Powerful Battery
  • 1.8m Drop Proof 1.8m Drop Proof
  • IP65 Sealing IP65 Sealing
  • UHF RFID (Impinj E310 Chip UHF RFID (Impinj E310 Chip
  • Barcode Scanning (Optional) Barcode Scanning (Optional)
  • Fingerprint Recognition (Optional) Fingerprint Recognition (Optional)
  • Cortex-A53 Octa-core 23GHz Cortex-A53 Octa-core 23GHz
  • 13MP Autofocus Camera 13MP Autofocus Camera
  • Dual-band WIFI Dual-band WIFI

Product Detail


SF509 Industrial Mobile Computer is an industrial rugged mobile computer with high extensibility. Android 11.0 OS, Octa-core processor, 5.2 inch IPS 1080P touch screen, 5000 mAh powerful battery, 13MP camera, fingerprint and facial recognition. PSAM and optional barcode scanning.

Industrial Mobile Computer Data Collector
Inventory Data Collection PDA

5.2 Inches High-resolution display, Full HD1920X1080, Providing a vibrant experience that is truly a feast for the eyes. You can adjust the screen brightness based on the surrounding light conditions so that your display is always clear and readable.

rfid ear tag reader
Portable RFID Scanner

Up to 5000 mAh rechargeable and replaceable battery satisfy your whole days work.
Also supports flash charging.

5.2 Inch Portable Data Collector PDA

Industrial IP65 design standard, water and dust proof. Withstanding 1.8 meters drop without damage.

Rugged UHF PDA
Rugged Barcode Terminal
Industrial Mobile PDA

Working temperate -20°C to 50°C suitable working for harsh environment

Rugged Mobile Terminal

Efficient 1D and 2D barcode laser scanner (Honeywell, Zebra or Newland) built-in to enable decoding different kinds of codes with high accuracy and high speed.

Android 1D/2D Barcode Handheld Data Terminal

Built in high sensitive NFC/ RFID UHF module with high UHF tags reading up to 200tags per second. Suitable for warehouse inventory, animal husbandry, foresting, meter reading etc

SF509 can be configured with capacitive or optical fingerprint sensor which have gained certification of FIPS201, STQC, ISO, MINEX, etc. It captures high -quality fingerprint images, even when the finger is wet and even when there is strong light.

Android Fingerprint Terminal

Widely application that satisfy your life much convenient.

Multiple Application Scenarios


Clothes wholesale




Express logistics


Smart power


Warehouse management


Health Care

VCG41N1268475920 (1)

Fingerprint recognition


Face recognition

  • Previous:
  • Next:

  • Performance
    CPU Cortex-A53 2.5 / 2.3 GHz Octa-core
    RAM+ROM 3 GB + 32 GB / 4 GB + 64 GB (optional)
    Expansion Supports up to 128 GB Micro SD card
    Operating System Android 8.1; GMS, FOTA, Soti MobiControl, SafeUEM supported Android 11; GMS, FOTA, Soti MobiControl, SafeUEM supported. Committed support for a future upgrade to Android 12, 13, and Android 14 pending feasibility
    Android 8.1
    WLAN IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna
    WWAN (China) 2G: 900/1800 MHz
    3G: WCDMA: B1,B8
    CDMA2000 EVDO: BC0
    TD-SCDMA: B34,B39
    4G: B1,B3,B5,B8,B34,B38,B39,B40,B41
    WWAN (Europe) 2G: 850/900/1800/1900MHz
    3G: B1,B2,B4,B5,B8
    4G: B1,B3,B5,B7,B8,B20,B40
    WWAN(America) 2G: 850/900/1800/1900 MHz
    3G: B1,B2,B4,B5,B8
    4G: B2,B4,B7,B12,B17,B25,B66
    WWAN (Others) Depending on the country’s ISP
    Bluetooth Bluetooth v2.1+EDR, 3.0+HS, v4.1+HS
    GNSS GPS/AGPS, GLONASS, BeiDou; internal antenna
    Physical Characteristics
    Dimensions 164.2 x 78.8 x 17.5 mm / 6.46 x 3.10 x 0.69 in.
    Weight < 321 g / 11.32 oz.
    Display 5.2” IPS LTPS 1920 x 1080
    Touch Panel Corning Gorilla Glass, multi-touch panel, gloves and wet handssupported
    Power Main battery: Li-ion, rechargeable, 5000mAh
    Standby: over 350 hours
    Continuous use: over 12 hours (depending on user environment)
    Charging time: 3-4 hours (with standard adaptor and USB cable)
    Expansion Slot 1 slot for Nano SIM card, 1 slot for Nano SIM or TF card
    Interfaces USB 2.0 Type-C, OTG, TypeC headphones supported
    Sensors Light sensor, proximity sensor, gravity sensor
    Notification Sound, LED indicator, vibrator
    Audio 2 microphones, 1 for noise cancellation; 1 speaker; receiver
    Keypad 4 front keys, 1 power key, 2 scan keys, 1 multifunctional key
    Developing Environment
    SDK Software Development Kit
    Language Java
    Tool Eclipse / Android Studio
    User Environment
    Operating Temp. -4 oF to 122 oF / -20 oC to 50 oC
    Storage Temp. -40 oF to 158 oF / -40 oC to 70 oC
    Humidity 5% RH – 95% RH non condensing
    DropSpecification Multiple 1.8 m / 5.9 ft. drops (at least 20 times) to the concreteacross the operating temperature range
    TumbleSpecification 1000 x 0.5m / 1.64 ft. falls at room temperature
    Sealing IP67 per IEC sealing specifications
    ESD ±15 KV air discharge, ±6 KV conductive discharge
    Data Collection
    Engine CM-Q module;Module based on Impinj E310
    Frequency 865-868 MHz / 920-925 MHz / 902-928 MHz
    Protocol EPC C1 GEN2 / ISO18000-6C
    Antenna Circular polarization (1.5 dBi)
    Power 1 W (+19 dBm to +30 dBm adjustable)
    R/W range 4 m
    Rear Camera 13 MP Autofocus with flash
    Front Camera(optional) 5 MP camera
    Frequency 13.56 MHz
    Protocol ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
    Chips M1 card (S50, S70), CPU card, NFC tags, etc.
    Range 2-4 cm
    Barcode Scanning (optional)
    1D Linear Scanner Zebra: SE965; Honeywell: N4313
    1D Symbologies UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of5, Codabar, MSI, RSS, etc.
    2D ImagerScanner Zebra: SE4710 / SE4750 / SE4750MR; Honeywell: N6603
    2D Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, DutchPostal (KIX), etc.


    Iris (optional)
    Rate < 150 ms
    Range 20-40 cm
    FAR 1/10000000
    Protocol  ISO/EC 19794-6GB/T 20979-2007
    Standard AC Adaptor, USB Cable, Lanyard, etc.
    Optional Cradle, Holster,etc.
